STANDARD FEATURES
- 1/2 in. (12 mm) model
- Interchangeable trim sets
- Heavy-duty union bonnet
- Different trim characteristics available (linear, equal percent,
quick open or double taper) - TFE chevron packing
- Stellite inlaid inner valves
- ANSI Class IV shutoff
- High pressure and temperature rating
- Encapsulated graphite body bonnet gasket
- Dual IEC 534 (NAMUR) accessory mounts
- Adjustable spring preload and up-travel stop
OPTIONAL FEATURES
- Butt and socket weld ends, BSPP, tube connection, and others
- Bonnet extensions for different temperature extremes
- Bellows packing solutions
- Reduced Emissions Kalrez (REK), graphite, spring-loaded chevron and others
- Exotic alloys available for complete valves or trims
- Stellited trims & Soft seats (PTFE & Kel-F) available
- TiN coating of inner valve stem and seat
- Purge or leak ports available
