InteliBifuel Lite
InteliBifuel Lite 100 package is a cost-effective, compact solution designed for the control of a bi-fuel system for engines with power output up to 100 kW. IBF Lite 100 is suitable for the rental market, pump, or power generation applications using various types of gas. IBF Lite 100 together with IntelBifuel Denox secures the safe operation of your bi-fuel system.
Smart control of bi-fuel solution at your variable speed application. The InteliBifuel Lite 100 enables a short time to market thanks to predefined functions but still provides you with the power to design your own functions at no extra cost.
The InteliBifuel Lite 100 offers:
- Control and monitor the engine running in dual fuel mode, with the possibility of a quick and easy switch to diesel anytime
- Solution for single-speed operation suitable for power generation, pumps or rental market with nominal power output up to 100 kW
- Smart control of the system based on various factors such as gas quality, temperature, and others, and the ability to adapt to changes in those factors
- Safe operation of the engine in bi-fuel mode thanks to ComAp InteliBifuel Denox controller, which ensures that the engine does not enter the knocking process
- Possibility of controlling Single point injection for high-pressure gas, where the gas is injected behind the turbocharger, or Fumigation applicable at low-pressure gas with injection in front of the turbocharger
- The capability of achieving significant diesel substitution thanks to our commissioning
- Robust design that meets the IP-69 certifications and ensures fits any application
- Large built-in PLC interpreter to suit your individual needs and design-demanding applications
- AirGate for easy connection to your equipment remotely, without worrying about your asset’s IP address
- Plug&Play support of the ComAp InteliVision 5 and 8 displays
- Communication with the engine management system via CAN using J1939 or another communication protocol
- Possibility of using freely available ComAp PC tools for configuration and monitoring
- Built-in event and performance log, which provides easy troubleshooting and warranty claim handling
- Product dimensions: 257,6 x 242 x 78,5 mm (10,14 x 9,53 x 3,09 in)
Key Features
- Control of bi-fuel system for applications with power output up to 100kW
- Control for high-pressure and low-pressure gas systems
- Algorithm with automatic compensation for gas quality changes
- Design suitable for harsh environments, IP-69
- Easy installation and commissioning
- Compatibility with InteliVision 5 and InteliVision 8 displays
- Power Generation: Used to convert diesel generators to run on a mix of diesel and natural gas, hydrogen, or other gasses to reduce fuel costs and emissions in stationary setups.
- Pumping Applications: Suitable for controlling engines that power industrial pumps.
- Rental Market: Its cost-effective and compact design makes it ideal for the rental industry, where equipment might be used in various locations and environments.
- Oil and Gas: Can be used to utilize associated or flare gas (which would otherwise be wasted) to fuel operations in the oil and gas industry.
- Mining: Employed in mining operations for various constant-speed power needs.
- Application: Bi-fuel control for single-speed engines used in power generation, pumps, and similar applications.
- Max Power Output:
- Lite 100: up to 100 kW
- Lite 500: up to 500 kW
- Fuel Types: Supports diesel + natural gas or hydrogen; tri-fuel operation possible with accessories.
- Gas Injection: Compatible with high-pressure single-point injection and low-pressure fumigation systems.
- Engine Protection: Integrates with the external InteliBifuel Denox anti-knock system for safe operation.
- Connectivity:
- CAN bus with J1939 protocol
- AirGate for easy remote connection
- Works with InteliVision 5 and InteliVision 8 displays
- I/O: Offers numerous configurable inputs/outputs; final counts depend on the controller version and expansion modules.
- Software: Fully configurable using free ComAp PC tools.
- Design/Rating: Rugged build with IP69 protection.
- Dimensions: 257.6 × 242 × 78.5 mm (10.14 × 9.53 × 3.09 in).
- Operating Temperature: –40°C to +80°C (core InteliBifuel rating; Lite versions also designed for harsh conditions).
- Certifications: CE, ABS, UL, CSA.
