- Industrial emissions monitoring for factories, manufacturing plants, and industrial facilities to ensure regulatory compliance
- Environmental air quality monitoring in CAAQMS to detect and measure organic pollutants
- Process control by tracking hydrocarbon levels within industrial operations to maintain efficiency and standards
- Combustion source monitoring in CEMS, including mixed fuel (hydrogen/helium) sample streams with varying oxygen content.
| Detection Limits | 0.050 ppm (10 sec. averaging time) |
| Flow Rate | 0.75 to 1.5 L/min. |
| Inputs | 16 Digital Inputs (Standard), 8 0 to 10 VDC Analog |
| Linearity | ±2% of span (at concentrations of 10 to 150% of span) |
| Response Time | 15 sec. (1 sec. average time) |
| Span Drift | <2% of range or 0.20 ppm (24 hr.) |
| Temperature (English) Operating | 59°F to 95°F |
| Temperature (Metric) Operating | 15°C to 35°C |
| Zero Noise | 0.025 ppmc RMS |
| Certifications/Compliance | ETL, CSA, UL, CE, UKCA |
| Description | Low Temperature |
| Measurement Range | Preset Ranges: 0 to 1, 10, 100, 1,000, 5000, and 10000ppmc; Custom Ranges: 0 to 1 to 10000ppmc |
| Mounting Options | Bench mounting (standard); Ears and handles, EIA; |
| Outputs | Selectable Voltage, RS232/RS485, TCP/IP, 10 Status Relays, Power Fail Indication; 0 to 20 or 4 to 20mA Isolated Current Output (optional) |
| Precision | 2.0% of reading or 0.1 ppm (whichever is larger) |
| Weight (English) | 50 lb. |
| Weight (Metric) | 22.7 kg |
| Zero Drift | <0.50ppm/day |
| Unit Size | Each |
