Description
FEATURES AND ADVANTAGES
- Diverse possibilities of saving data: by interval, by condition or by event
- Actual value, minimum, maximum, mean value, sum, intensity, peak
- Comprehensive alarm functions via SMS, modem call or switch contact
- Quick retrieval of the actual measuring values via SMS
- Failsafe data saving for up to 600.000 records
- Quick and assistant-supported parametrisation
- Easy connection of diverse sensors by automatic internal input configuration
- Extension options
- – MDL-AE4: 4 x additional analogue inputs incl. channel extension
- – MDL-AE8: 8 x additional analogue inputs incl. channel extension
- – Channel extension for MDL 8/3 for additional measurement variables
- – Second serial interface for serial sensors or connection of radio device (e.g. SOMMER DFM-433) to connect to other weather stations via radio
TECHNICAL DETAILS
CONNECTION POSSIBILITIES
- 8 x analogue inputs
- 3 x inputs wind direction and wind speed
- 1 x counter input (precipitation)
- 1 x switch output for e.g. GSM modem for energy saving remote data retrieval
- 1 x switch output for alarm
- 1 x serial interface for connection modem (analogue, GSM, GPRS) for remote data retrieval
- Extension possible for up to 40 measuring channels
INPUTS
- Analogue voltage 0 … 2.5 V (22 Bit correlates 1 µV)
- Analogue current 0 … 20 mA or 4 … 20 mA (22 Bit correlates 0.1 µA)
- Analog resistance 0 … 10 kOhm
- Frequency wind 2 … 1500 Hz, resolution 0.1 Hz
- Impulse precipitation 0 … 10 Hz
OTHERS
- Outputs solid state relay, max. 1.8 A /24 VDC
- Interface (digital) RS 232; 9.6 – 115 kBd
- Memory 2 MB (correlates app. 600.000 records)
- Supply data logger 5.5 … 20 V; max. 30 mA (without sensors, measuring time approx. 2 sec.); standby 100 µA
- Supply sensors 5 or 15 VDC; 2.5 V reference voltage, 1 mA or 0.4 mA reference current, max. 50 mA each sensor
